WATTS® 0820955 1/4-Turn Boiler Drain, 1/2 in Inlet Connection, MNPT Inlet Connection, 1/2 in Outlet Connection
WATTS® 0820955 1/4-Turn Boiler Drain, 1/2 in Inlet Connection, MNPT Inlet Connection, 1/2 in Outlet Connection
| Body Material | : | Brass |
| Body Pattern | : | Angle |
| Function Type | : | Drain |
| Inlet Connection Size | : | 1/2 in |
| Inlet Connection Type | : | MNPT |
| Lead-Free Compliant | : | Yes |
| Length | : | 2-1/4 in |
| Maximum Working Pressure | : | 200 psi |
| Operating Temperature Rating | : | 250 deg F |
| Outlet Connection Size | : | 1/2 in |
| Outlet Connection Type | : | MGHT |
| Product Family | : | BD-QT Series |
| Seal Material | : | PTFE |
| Width | : | 3-3/8 in |
This 1/2 inch angle pattern quarter turn forged brass boiler drain shutoff is designed for water service use in commercial and residential hydronic heating systems. It provides positive shutoff for boiler drain or sill cock applications. This shutoff consists of a forged brass body construction with dual connection for either threaded and solder and 3/4 inch hose thread connection, PTFE stem packing, and rugged aluminum tee handle. The maximum pressure is 200 psi (14 bar) WOG and maximum temperature is 250 degrees F (121 degrees C).
WATTS® 1/4-Turn Boiler Drain, 1/2 in Inlet Connection, MNPT Inlet Connection, 1/2 in Outlet Connection, MGHT Outlet Connection, Brass Body, PTFE Seal, Angle Body Pattern, 200 psi Maximum Working Pressure, 250 deg F, 2-1/4 in Length, 3-3/8 in Width, Yes, BD-QT Series, Drain Function Type
- Forged brass body
- Angle pattern
- Dual inlet connection
- Hose thread outlet
