Southwire® A50039-1AA Mini-Split Cable, 16 AWG Wire, 2 Conductors, 50 ft Length, Shielded: Yes, 300 V, Copper Conductor
Southwire® A50039-1AA Mini-Split Cable, 16 AWG Wire, 2 Conductors, 50 ft Length, Shielded: Yes, 300 V, Copper Conductor
Manufacturer: Southwire Company, LLC
Brand: Southwire®
Part #: 326131
MPN: A50039-1AA
CPN:
| Conductor Material | : | Copper |
| Function Type | : | Cable |
| Jacket Color | : | Gray |
| Jacket Material | : | PVC |
| Length | : | 50 ft |
| Number of Conductors | : | 2 |
| Package Type | : | Coil |
| Product Type | : | Cable |
| Shielded | : | Yes |
| Solid/Stranded | : | Stranded |
| Voltage Rating | : | 300 V |
| Wire Size | : | 16 AWG |
For use in Remote Control, Signaling, and Power-Limited circuits per NEC Article 725. Sizes 22 AWG - 16 AWG can also be used as communication circuits per NEC Article 800. Can be used in security, sound and audio, speaker cable, public address, intercom, sound reinforcement, alarm and access control circuits and power-limited controls. The conductors are cabled together; lay length varies depending on conductor count and gauge size.
Southwire® Mini-Split Cable, 16 AWG Wire, 2 Conductors, 50 ft Length, Shielded: Yes, 300 V, Stranded Solid/Stranded, Copper Conductor, PVC Jacket, Gray Jacket, Cable Function Type
- Flame Test: UL 1666
- Cable Type: CL3R, Also, CMR where UL permits (Sizes 16 AWG and smaller)
- Sunlight Resistant
