LEESON® C420 Fan and Blower Motor, 1/4 hp, 1/3 hp Motor, 115 V, 1 ph, 1140 rpm, 1725 rpm Motor, CCW Rotation Direction
LEESON® C420 Fan and Blower Motor, 1/4 hp, 1/3 hp Motor, 115 V, 1 ph, 1140 rpm, 1725 rpm Motor, CCW Rotation Direction
Manufacturer: Regal Rexnord Corporation
Brand: LEESON®
Part #: 391047
MPN: C420
CPN:
| Amperage Rating | : | 6.4/9 A |
| Bearing Type | : | Ball |
| Enclosure Type | : | ODP |
| Function Type | : | Motor |
| Motor HP | : | 1/4 hp, 1/3 hp |
| Motor RPM | : | 1140 rpm, 1725 rpm |
| Mounting Type | : | Horizontal, Vertical |
| NEMA Frame Size | : | 56 |
| Packaged Depth | : | 13.69 in |
| Packaged Height | : | 9.5 in |
| Packaged Width | : | 7.31 in |
| Phase | : | 1 ph |
| Rotation Direction | : | CCW |
| Service Factor | : | 1.25 |
| Shaft Diameter | : | 5/8 in |
| Shipping Weight | : | 31 lb |
| Voltage Rating | : | 115 V |
LEESON® Fan and Blower Motor, 1/4 hp, 1/3 hp Motor, 115 V, 1 ph Phase, 1140 rpm, 1725 rpm Motor, CCW Rotation Direction, Ball Bearing, ODP Enclosure, 5/8 in Dia Shaft, 56 NEMA, Service Factor: 1.25, 6.4/9 A, Motor Function Type, Horizontal, Vertical Mounting
- Automatic reset thermal protector prevents overheating.
- IRIS® insulation system offers superior protection for use with a variable frequency drive.
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
- Ambient temperature up to 70 deg C allows for consistent operation in a range of environments and applications.
- Vertical/horizontal mounting for proper placement of the fan within airflow.
- LEESON® motors. Motors and solutions at our core™
