LEESON® C216 General-Purpose Motor, 1/3 hp Motor, 115/208-230 V, 1 ph, 1425 rpm, 1725 rpm Motor, CCW Rotation Direction
LEESON® C216 General-Purpose Motor, 1/3 hp Motor, 115/208-230 V, 1 ph, 1425 rpm, 1725 rpm Motor, CCW Rotation Direction
Manufacturer: Regal Rexnord Corporation
Brand: LEESON®
Part #: 422919
MPN: C216
CPN:
| Amperage Rating | : | 3/3.2/6 A |
| Bearing Type | : | Ball |
| Enclosure Type | : | ODP |
| Function Type | : | Motor |
| Motor HP | : | 1/3 hp |
| Motor RPM | : | 1425 rpm, 1725 rpm |
| NEMA Frame Size | : | 56 |
| Packaged Depth | : | 13.69 in |
| Packaged Height | : | 7.5 in |
| Packaged Width | : | 7.13 in |
| Phase | : | 1 ph |
| Rotation Direction | : | CCW |
| Service Factor | : | 1.35 |
| Shaft Diameter | : | 5/8 in |
| Shipping Weight | : | 18 lb |
| Voltage Rating | : | 115/208-230 V |
LEESON® General-Purpose Motor, 1/3 hp Motor, 115/208-230 V, 1 ph Phase, 1425 rpm, 1725 rpm Motor, CCW Rotation Direction, Ball Bearing, ODP Enclosure, 5/8 in Dia Shaft, 56 NEMA, Service Factor: 1.35, 3/3.2/6 A, Motor Function Type
- UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
- Premium efficiency promotes improved reliability.
- Heavy-duty, rolled steel construction ensures motor durability.
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
- LEESON® motors. Motors and solutions at our core™
