LEESON® C1160 General-Purpose Motor, 1-1/2 hp Motor, 115/208-230 V, 1 ph, 1725 rpm Motor, CCW Rotation Direction
LEESON® C1160 General-Purpose Motor, 1-1/2 hp Motor, 115/208-230 V, 1 ph, 1725 rpm Motor, CCW Rotation Direction
Manufacturer: Regal Rexnord Corporation
Brand: LEESON®
Part #: 361369
MPN: C1160
CPN:
| Amperage Rating | : | 8.2/8.4/16.4 A |
| Bearing Type | : | Ball |
| Enclosure Type | : | ODP |
| Function Type | : | Motor |
| Motor HP | : | 1-1/2 hp |
| Motor RPM | : | 1725 rpm |
| NEMA Frame Size | : | 56H |
| Packaged Depth | : | 15.63 in |
| Packaged Height | : | 7.5 in |
| Packaged Width | : | 9.88 in |
| Phase | : | 1 ph |
| Rotation Direction | : | CCW |
| Service Factor | : | 1.15 |
| Shaft Diameter | : | 5/8 in |
| Shipping Weight | : | 35 lb |
| Voltage Rating | : | 115/208-230 V |
LEESON® General-Purpose Motor, 1-1/2 hp Motor, 115/208-230 V, 1 ph Phase, 1725 rpm Motor, CCW Rotation Direction, Ball Bearing, ODP Enclosure, 5/8 in Dia Shaft, 56H NEMA, Service Factor: 1.15, 8.2/8.4/16.4 A, Motor Function Type
- UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
- Premium efficiency promotes improved reliability.
- Heavy-duty, rolled steel construction ensures motor durability.
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
- LEESON® motors. Motors and solutions at our core™
