LEESON® B319 General-Purpose Motor, 3/4 hp Motor, 115/230 V, 1 ph, 1800 rpm Motor, 1-Speed, CCW Rotation Direction
LEESON® B319 General-Purpose Motor, 3/4 hp Motor, 115/230 V, 1 ph, 1800 rpm Motor, 1-Speed, CCW Rotation Direction
Manufacturer: Regal Rexnord Corporation
Brand: LEESON®
Part #: 379143
MPN: B319
CPN:
| Amperage Rating | : | 5/10 A |
| Bearing Type | : | Ball |
| Depth | : | 10.72 in |
| Enclosure Type | : | ODP |
| Frequency Rating | : | 60 Hz |
| Function Type | : | Motor |
| Motor HP | : | 3/4 hp |
| Motor RPM | : | 1800 rpm |
| Mounting Type | : | Extended Stud, Resilient Base |
| NEMA Frame Size | : | 56 |
| Number of Speeds | : | 1 |
| Packaged Depth | : | 12.44 in |
| Packaged Height | : | 8.75 in |
| Packaged Width | : | 8.06 in |
| Phase | : | 1 ph |
| Rotation Direction | : | CCW |
| Service Factor | : | 1.25 |
| Shaft Diameter | : | 5/8 in |
| Shipping Weight | : | 23 lb |
| Voltage Rating | : | 115/230 V |
LEESON® General-Purpose Motor, 3/4 hp Motor, 115/230 V, 1 ph Phase, 1800 rpm Motor, 1 -Speed, CCW Rotation Direction, Ball Bearing, ODP Enclosure, 5/8 in Dia Shaft, 56 NEMA, Service Factor: 1.25, 10.72 in D, 5/10 A, Motor Function Type, 60 Hz Frequency, Extended Stud, Resilient Base Mounting
- UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
- Premium efficiency promotes improved reliability.
- Heavy-duty, rolled steel construction ensures motor durability.
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
- LEESON® motors. Motors and solutions at our core™
