| Body Material | : | Brass |
| Depth | : | 2.375 in |
| Differential Pressure | : | 20 PSI |
| Electrical Connection Type | : | Screw Terminal |
| Flow Coefficient | : | 3.5 Cv |
| Flow Pattern | : | 2/2 |
| Function Type | : | Zone Valve |
| Height | : | 4 in |
| Includes End Switch | : | Yes |
| Inlet Connection Size | : | 3/4 in |
| Inlet Connection Type | : | Sweat |
| Maximum Fluid Temperature | : | 200 F |
| Maximum Operating Temperature | : | 125 F |
| Maximum Working Pressure | : | 125 PSI |
| Minimum Fluid Temperature | : | 50 F |
| Number of Ports | : | 2 |
| Number of Positions | : | 2 |
| Outlet Connection Size | : | 3/4 in |
| Outlet Connection Type | : | Sweat |
| Package Quantity | : | 1 |
| Packaged Depth | : | 5.9 in |
| Packaged Height | : | 3.7 in |
| Packaged Width | : | 5.1 in |
| Product Family | : | V8043 Series |
| Product Type | : | Zone Valve |
| Shipping Weight | : | 2 lbs |
| VA Rating | : | 7.7 VA |
| Valve Action | : | Normally Closed |
| Voltage Rating | : | 24 V |
| Width | : | 3.5 in |
- resideo-hydronic-heating-solutions-brochure-french-24758
- whole-home-hydronic-heating-and-potable-water-solutions-english-17555
- installation-instructions-for-v4043-v4044-v8043-v8044-zone-valves-24765
- honeywell-home-5000-series-zone-valve-sell-sheet-spanish-24757
- product-data-for-v4043-v4044-v8043-v8044-motorized-valves-english-24761
- v8043-5000-series-zone-valves-submittal-sheet-24763
