| BTU Cooling Rating (Custom) | : | 180,000 BTU/h |
| BTU Cooling Rating | : | 182,000 BTU/h |
| Compressor Oil Type | : | POE Oil |
| Compressor Type | : | Scroll |
| Depth | : | 12.93 in |
| Discharge Line Size | : | 7/8 in |
| For Use With | : | HVAC System |
| Function Type | : | Compressor |
| Height | : | 22.21 in |
| Locked Rotor Amps (LRA) | : | 173 A |
| Motor HP | : | 15 HP |
| Package Quantity | : | 1 |
| Packaged Depth | : | 18 in |
| Packaged Height | : | 28 in |
| Packaged Width | : | 16 in |
| Phase | : | 3 ph |
| Product Family | : | ZP Series |
| Product Weight | : | 146 lbs |
| Rated Load Amps (RLA) | : | 26.9 A |
| Refrigerant Type | : | R-410A |
| Shipping Weight | : | 150 lbs |
| Suction Line Size | : | 1-3/8 in |
| Tonnage (Custom) | : | 15.0 Ton |
| Tonnage | : | 15.0 Ton |
| UL Listed | : | Yes |
| Voltage Rating | : | 460 V |
| Width | : | 11.73 in |
