| BTU Cooling Rating (Custom) | : | 12,000 BTU/h |
| BTU Cooling Rating | : | 9,700 BTU/h |
| Compressor Oil Type | : | POE Oil |
| Compressor Type | : | Hermetic |
| Depth | : | 10.3 in |
| Discharge Line Size | : | 3/8 in |
| For Use With | : | HVAC System |
| Function Type | : | Compressor |
| Height | : | 9.8 in |
| Locked Rotor Amps (LRA) | : | 51 A |
| Motor HP | : | 1 HP |
| Package Quantity | : | 1 |
| Packaged Depth | : | 14.3 in |
| Packaged Height | : | 13.4 in |
| Packaged Width | : | 13.3 in |
| Phase | : | 1 ph |
| Product Family | : | RS Series |
| Product Weight | : | 39.2 lbs |
| Rated Load Amps (RLA) | : | 10 A |
| Refrigerant Type | : | R-22~R-404A |
| Shipping Weight | : | 48.75 lbs |
| Suction Line Size | : | 1/2 in |
| Tonnage (Custom) | : | 1.5 Ton |
| Tonnage | : | 1.25 Ton |
| UL Listed | : | Yes |
| Voltage Rating | : | 208/230 V |
| Watts | : | 1,590 W |
| Width | : | 7.1 in |
