Copeland™ 950-0264-03 Condenser Fan Motor, 1/6 hp Motor, 460 V, 3 ph, 1550 rpm Motor, Permanent Split Capacitor Motor
Copeland™ 950-0264-03 Condenser Fan Motor, 1/6 hp Motor, 460 V, 3 ph, 1550 rpm Motor, Permanent Split Capacitor Motor
Manufacturer: Copeland LP
Brand: Copeland™
Part #: 213104
MPN: 950-0264-03
CPN:
| Amperage Rating | : | 0.44 A |
| Depth | : | 8 in |
| Enclosure Type | : | TEAO |
| Frequency Rating | : | 50/60 Hz |
| Function Type | : | Motor |
| Height | : | 4.1 in |
| Motor HP | : | 1/6 hp |
| Motor RPM | : | 1550 rpm |
| Motor Type | : | Permanent Split Capacitor |
| Mounting Type | : | Foot |
| NEMA Frame Size | : | 51 |
| Number of Speeds | : | 1 |
| Phase | : | 3 ph |
| Rotation Direction | : | Counter Clockwise |
| Shaft Diameter | : | 5/16 in |
| Voltage Rating | : | 460 V |
| Width | : | 4.2 in |
Copeland™ Condenser Fan Motor, 1/6 hp Motor HP, 460 V, 3 ph Phase, 1550 rpm Motor RPM, Permanent Split Capacitor Motor, TEAO Enclosure, 51 Frame, 1 Speed, 5/16 in Shaft Diameter, 4.1 in Height, 4.2 in Width, 8 in Depth, Counter Clockwise Rotation Direction, 0.44 A, Motor Function Type, 50/60 Hz Frequency, Foot Mounting
