Apollo® 1061410 Safety Relief Valve With Oversized Outlet, 3/4 x 1 in Connection, FNPT Connection Type, 160 psi Pressure
Apollo® 1061410 Safety Relief Valve With Oversized Outlet, 3/4 x 1 in Connection, FNPT Connection Type, 160 psi Pressure
Manufacturer: Aalberts Integrated Piping Systems
Brand: Apollo®
Part #: 208276
MPN: 1061410
CPN:
| Body Material | : | Bronze |
| Connection Size | : | 3/4 x 1 in |
| Connection Type | : | FNPT |
| Depth | : | 2-1/4 in |
| Function Type | : | Valve |
| Height | : | 5-1/4 in |
| Maximum Fluid Temperature | : | 250 deg F |
| Maximum Working Pressure | : | 160 psi |
| Minimum Fluid Temperature | : | 32 deg F |
| Package Quantity | : | 1 Carton |
| Pressure Range | : | 160 psi |
| Product Family | : | 10 Series |
| Product Type | : | Valve |
| Product Weight | : | 2.26 lb |
| Width | : | 3 in |
ASME Section IV capacity certified bronze safety relief valve for protection of hot water heating boilers, systems and similar equipment. It can be pre-set to any pressure ranging from 15 to 160 psig (1 to 11 bar) at 250 degF (121 degC) max.
Apollo® Safety Relief Valve, 3/4 x 1 in Connection, Connection Type: FNPT, 160 psi Pressure, Bronze Body, 160 psi Maximum Working Pressure, 32 deg F Minimum Fluid Temperature, 250 deg F Maximum Fluid Temperature, 5-1/4 in Height, 3 in Width, 2-1/4 in Depth, 10 Series, Valve Function Type
- Sizes: 3/4" - 2" (20 - 50mm)
- ASME Section IV Certified Capacity
- Corrosion Resistant Construction
