| Body Material | : | Brass |
| Inlet Connection Size | : | 3/4 in |
| Inlet Connection Type | : | Copper |
| Lead-Free Compliant | : | Yes |
| Length | : | 3.15 in |
| Maximum Working Pressure | : | 200 WOG |
| NSF Specifications | : | NSF 372, NSF 61 |
| Operating Temperature Rating | : | 180 deg F |
| Outlet Connection Size | : | 3/4 in |
| Outlet Connection Type | : | Copper |
| Package Quantity | : | 10 Carton |
| Product Family | : | 521LF Series |
| Top to Inlet Center | : | 1.52 in |
The 521CLF Lead-Free Brass Swing Check Valve in the CxC (Copper to Copper) configuration combines the benefits of lead-free brass construction with a swing-type design for reliable flow control. With a pressure rating of 200 WOG, this valve ensures durability and environmental safety. Solder ends meet ASME B16.18 standards for sizes 1/2" to 4", and the valve is subjected to testing in accordance with MSS-SP-82.
Matco-Norca™ Swing Check Valve, Product Family: 521LF Series, 3/4 in Inlet Connection, Copper Inlet Connection, 3/4 in Outlet Connection, Copper Outlet Connection, Brass Body, 200 WOG Maximum Working Pressure, 1.52 in Top to Inlet Center, 3.15 in Length, 180 deg F Operating Temperature, NSF Specifications: NSF 372, NSF 61, Lead-Free Compliant: Yes
- 125 SWP
- 180 deg F Working Temperature
- Lead Free Cast Brass
- Swing Type
