D-VAC Sales® H2O Coil™ H2O-2-1718 Hot Water Duct Coil, 63642 Btu/hr BTU, 2 Rows, 1/2 in Tube Diameter, Copper Tube
D-VAC Sales® H2O Coil™ H2O-2-1718 Hot Water Duct Coil, 63642 Btu/hr BTU, 2 Rows, 1/2 in Tube Diameter, Copper Tube
Manufacturer: D-VAC Sales Inc
Brand: D-VAC Sales®
Part #: 256445
MPN: H2O-2-1718
CPN:
| BTU Rating | : | 63642 Btu/hr |
| Connection Size | : | 7/8 in |
| Connection Type | : | OD Tube |
| Fin Material | : | Aluminum |
| Flow Rate | : | 7 gpm |
| Height | : | 19-1/2 in |
| Number of Rows | : | 2 |
| Product Family | : | H2O Coil™ H2U/H2O Series |
| Tube Diameter | : | 1/2 in |
| Tube Material | : | Copper |
| Width | : | 20 in |
D-VAC Sales® Hot Water Duct Coil, 63642 Btu/hr BTU, 2 Rows, 1/2 in Tube Diameter, Copper Tube, Aluminum Fin, 7/8 in Connection, Connection Type: OD Tube, 7 gpm Flow Rate, 20 in Width, 19-1/2 in Height, H2O Coil™ H2U/H2O Series
- Built to ARI 410 Certification
- Galvanized Steel 16 ga Frame
- Aluminum Fins 0.0045 Thickness
- Copper Tubing, 1/2 in With 0.017 Wall
- Max 2500 psi Ultimate Pressure
- BTU Outputs From 5000 to 50000
- Horizontal and Vertical Installation
