| BTU Cooling Rating (Custom) | : | 18,000 BTU/h |
| BTU Cooling Rating | : | 17,000 BTU/h |
| Compressor Oil Type | : | POE Oil |
| Compressor Type | : | Scroll |
| Depth | : | 24.1 in |
| For Use With | : | HVAC System |
| Function Type | : | Compressor |
| Height | : | 16.6 in |
| Minimum Circuit Ampacity (MCA) | : | 21 A |
| Motor HP | : | 1-1/3 HP |
| Package Quantity | : | 1 |
| Packaged Depth | : | 31 in |
| Packaged Height | : | 20 in |
| Packaged Width | : | 22 in |
| Phase | : | 1 ph |
| Product Family | : | FPAK Series |
| Product Weight | : | 113 lbs |
| Rated Load Amps (RLA) | : | 15.7 A |
| Refrigerant Type | : | R-134a |
| Suction Line Size | : | 5/8 in |
| Tonnage (Custom) | : | 1.5 Ton |
| Tonnage | : | 1.5 Ton |
| UL Listed | : | Yes |
| Voltage Rating | : | 208/230 V |
| Width | : | 18.3 in |
